| MECHANICAL DATA |
| Keys |
102 keys + 2 mouse buttons |
| Key top style |
Protuberant rectangular keys with tactile feeling |
| Key travel |
1.50mm±0.10mm |
| Actuation Force |
1.5N±0.2N (pressure point ) |
| Touch pad |
sealed and ruggedized tough touchpad |
| Touchpad cover |
Composite |
| More than Lifetime 10 million strokes |
| Mutual capacitance sensing |
| X/Y axis location detection resolution |
40 Counts /mm |
| X/Y position report |
relative |
| Output (self-detectable depending on cable) |
USB |
| Tracking speed |
Maximum 1,016 m/sec |
| Power supply voltage |
5VDC ± 0.25V |
| Current rating (active mode) |
< 10 mA |
| G.W. |
≈0.8KGs |
| ELECTRICAL DATA |
| Supply Voltage |
DC +5V±5% |
| Current Rating |
30mA when backlight is off, 300mA with backlight on |
| Meet MIL-STD-461G (EMC, EMI, EMS, ESD) |
| 1 |
CE101 25Hz - 10kHz Conducted Emissions, Audio Frequency Currents, Power leads |
| 2 |
CE102 10kHz -10MHz Conducted Emissions, Radio Frequency Potentials, Power leads |
| 3 |
CS101 25Hz - 150kHz Conducted Susceptibility, Power Leads |
| 4 |
CS106 Conducted Susceptibility, Transients, Power Leads |
| 5 |
CS112 Electrostatic Discharge Susceptibility |
| 6 |
CS114 4kHz -400MHz Conducted Susceptibility, Bulk Cable injection |
| 7 |
CS115 Conducted Susceptibility, Bulk Cable injection, Impulse Excitation |
| 8 |
CS116 10kHz - 100MHz Conducted Susceptibility, Damped Sinusoidal Transients, Cables and Power Leads |
| 9 |
RE101 25Hz -100kHz Radiated Emissions, Magnetic Field |
| 10 |
RE102 10kHz - 18GHz Radiated Emissions, Electric Field |
| 11 |
RS101 25HZ - 100kHz Radiated Susceptibility, Magnetic Field |
| 12 |
RS103 10kHz - 40GHz Radiated Susceptibility, Electric Field |
| MIL-STD-810F (wide temperature, shock, vibration, humidity etc.). |
| Lifespan |
> 5 years |
| Switch Contact Material |
carbon-on-gold key switch technology |
| Interface |
USB |
| OS |
All Windows, Linux, Unix, Mac OSX, Vxworks, Android,
(U-cos--To be confirmed).
|
| ENVIRONMENTAL ADAPTABILITY |
| Operating temperature |
-40℃ to +75℃ |
| Storage temperature |
-45℃ to +85℃ |
| Operating RH |
3%~95% |
| Atmospheric pressure |
60-106Kpa |
| Saline mist |
96 hours, IEC 60512-6 |
| Damp heat test at +40℃ |
21 days, IEC 60512-6 |
| Dry heat test at +85℃ |
10 days, IEC 60512-6 |
| RELIABILITY |
|
RoHS compliant, CE and FCC certified, MIL-STD-461G (EMC, EMI, EMS, ESD) and MIL-STD-810F (wide temperature, shock, salt mist, vibration, fungus, humidity etc.)
|
| Protection Level |
IP65 dynamic (front panel) |
| Key Lifespan |
>5 million actuations |
| MTBF |
>20000H |
| MTTR |
<30min |
| APPLICATIONS |
Vehicle, aerospace, naval, defense, maritime, Radar, console, portable rugged laptop, UAV ground station etc. |
